CONCH PID Temperature Controller

Our PID temperature controller offers exceptional performance and reliability, making it an ideal choice for diverse applications. With its precise control capabilities, it ensures accurate temperature setpoints, minimizing temperature fluctuations and ensuring consistent product quality.

分享到

PID Temperature Controller • 16 bit microcomputer computing core PID + SELF TUNING
• Various input signals (thermocouple, platinum resistor, analog signal...)
• Optional main control output: relay, pulse voltage, linear analog signal
• Can drive various contactors, SSR, SCR and motor valves etc
• Programmable reverse/normal phase control (heating or cooling process)
• Dual output models can be used for heating/cooling bidirectional PID control
• SV target value can achieve remote setting function (RSV) by analog signal input
• 26 types of alarm modes selection can be added with disconnection detection alarm (HBA) function
• Retransmission function can convert PV value or control output into analog signal output
• With manual output mode

PID Temperature Controller • Serial communication supports ModBus' RTU and ASCII formats, the maximum rate can reach to 38400 bit/s
• Program control provides 16 sets number of temperature segments, can freel planning execution intervals and repetition times
